SMA Sunny TriPower STP 5.0 Smart Energy Hybrid Inverter – WHOLESALE SUPPLIER

Technical data:
Input (PV DC)
Max. PV (DC) array power Input: 7500 Wp
MPP voltage range: 210 – 800 V
Min. input voltage / initial input voltage: 150 V / 180 V
Number of independent MPP inputs / strings per MPP input: 2 / A:1; B:1
Max. input current – input A / input B: 12.5 A / 12.5 A
Battery
Battery connection type: Lithium-ion
Battery Voltage range 150 V to 600 V
Max. charging current / max. discharging current: 30 A / 30 A
AC connection
Rated AC connection power (at 230 V, 50 Hz): 5000 W
Nominal AC connection voltage: 3 / N / PE; 220 V (230V; 240V) / 380 V (400V; 415V)
AC voltage range: 156 V to 277 V
AC power frequency/range: 50 Hz / 45 Hz to 55 Hz
Rated output current: 3 x 7.3 A
Feed-in phases/connection phases: 3 / 3
AC backup
Max. connectable power for backup load: 13800 W
Rated Output (AC backup) Power 1~/3~ (at 230 V, 50 Hz): 1660 W / 5000 W
General data and Equipment
Dimensions (W/H/D): 500 mm / 598 mm / 173 mm
Weight: 30 kg
Noise emission, typical: 30 dB(A)
Degree of protection: IP65
Number of interfaces: Wi-Fi/Ethernet/BAT-CAN: 1 / 2 / 1
Number of digital inputs / outputs: 5 / 1
Shade management: SMA ShadeFix (integrated)
Warranty: 5 / 10 years (When device is registered via the SMA product registration page (sma-service.com)
More information:
SMA SUNNY TRIPOWER 5.0 / 6.0 / 8.0 / 10.0 SMART ENERGY Hybrid inverter. DATASHEET
SMA Sunny Tripower Smart Energy
HOW TO GET IT?
You can get the SMA SUNNY TRIPOWER STP 5.0 SMART ENERGY HYBRID INVERTER  from our online store website AAK DISTRIBUTION BV
Add to wishlist
Compare
Category: Tags: ,

Description

SMA SUNNY TRIPOWER STP 5.0 SMART ENERGY HYBRID INVERTER
The new three-phase hybrid inverter SMA Sunny Tripower Smart Energy is the  two-in-one solution for solar power supply in the residential sector.
In it, SMA combines intelligent technologies and integrated services into a space-saving compact solution that is simple and convenient. The system can be expanded at any time and also integrates electric mobility or heat pumps. The integrated backup power function secures the household’s power supply even in the event of a grid failure. That makes domestic PV systems comprehensive, smart energy systems with solar energy self-sufficiency of up to 100 percent.
The SMA Sunny Tripower Smart Energy hybrid inverters is available in power classes from 5-10kW and is compatible with BYD’s high-voltage batteries:
BYD Battery-Box Premium HVS 5.1 // 7.7 // 10.2 // 12.8 set
BYD Battery-Box Premium HVM 11.0 // 13.8 // 16.6 // 19.3 // 22.1 set
